| Feature |
Value |
| Type |
HSV - 1/4" |
HSV - 1/2" |
| Medium |
Compressed air (Filtered & lubricated) |
| Design |
Slide valve without return spring |
| Connection |
1/4"BSP |
1/2" BSP |
| Orifice size |
7 mm |
13 mm |
| Operating pressure range |
0 to 10 kg/sq.cm |
| Temperature range |
-100 C to + 600 C |
| Nominal flow rate LPM |
1000 |
2000 |
| Type of mounting |
Line fitting (screw in thread) |
| Material |
Aluminium, Nitrile. |
|
|
|
